Waterproof / Reusable PP Corrugated Plastic Sheet / PP Coroplast Sheet / PP Hollow Sheet
specifications
PP Hollow Sheet
Width:1220mm,2050mm
Length:limitless
Thickness:2 ~10mm
Colors:as per customer's request
Introduction:
Oursign PP hollow sheets are light, high strength, anticorrosive, waterproof and moisture proof, etc. They can be used to display, screen printing, packaging. S-corrugated board is the one of Oursign's special products. The package box made of this media is with high intensity and long durability. And this media can be reused and easily be cleaned. So it can also be made to the products with the function of electric conduction, and made to the products which can anti static and anti UV. It's widely used in the field of advertisement, package and electronics.buhui
Features:
1. Light weight.
2. High strength.
3. Anti-corrosive.
4. Water proof and moisture proof.
5. Weather resistant (UV, rain, typhoon and frost).
6. Anti-static.
Application:
1. Billboard .
2. screen printing.
3. Exhibition booth decoration.
4. Displays (indoor and outdoor).
5. packing box.
6. Insulator, cushion material, tray.
Specification:
| Name | Width(mm) * Length(mm) | Thickness±0.1(mm) | Standard Weight (gsm) | Weight Range (gsm) |
| PP Hollow Sheet | 1220*2440 2050*3050 | 2 | 450 | 300~600 |
| 3 | 500 | 360~800 | ||
| 4 | 700 | 550~1000 | ||
| 5 | 900 | 700~1200 | ||
| 6 | 1200 | 900~1600 | ||
| 1220*2440 | 7 | 1400 | 1200~1800 | |
| 8 | 1600 | 1600~2000 | ||
| 9 | 1800 | 1700~2200 | ||
| 10 | 2000 | 1800~2200 |
Main tech parameter :
Specifications:
| Item | Unit | Thickness & Physical Performance Parameter | ||||||||
| 2mm | 3mm | 4mm | 5mm | 6mm | 7mm | 8mm | 9mm | 10mm | ||
| Raw Material | PP | PP | PP | PP | PP | PP | PP | PP | PP | |
| Length | mm | Custom- ization |
Custom- ization |
Custom- ization |
Custom- ization |
Custom- ization |
Custom- ization |
Custom- ization |
Custom- ization |
Custom- ization |
| Max. Width | mm | 1700 | 1700 | 1700 | 1700 | 1700 | 1700 | 1700 | 1700 | 1700 |
| Gram per Square Meter |
GSM | 400 | 450 | 650 | 850 | 1000 | 1400 | 1600 | 1800 | 2000 |
| Tension Fracture |
N | ≥200 | ≥250 | ≥300 | ≥350 | ≥400 | ≥450 | ≥500 | ≥550 | ≥600 |
| Elongation at Break |
% | ≥50 | ≥50 | ≥50 | ≥50 | ≥50 | ≥50 | ≥50 | ≥50 | ≥50 |
| Horizontal Compression Ratio |
N | ≥700 | ≥900 | ≥1000 | ≥2500 | ≥3000 | ≥3500 | ≥4000 | ≥4500 | ≥5000 |
| Vertical Compression Ratio |
N | ≥90 | ≥150 | ≥350 | ≥600 | ≥600 | ≥700 | ≥750 | ≥800 | ≥1000 |
| Tearing Force | N | ≥50 | ≥60 | ≥70 | ≥80 | ≥100 | ≥150 | ≥160 | ≥180 | ≥210 |
